Bình lọc cát Emaux V500

Polyethylene tank has been well-received by the industry due to the durability, trustworthy performance and economical reason. With UV-resistant material used, it is able to operate under prolong sunlight for years of reliability. “P” Series (P350-P700) top mount filters are equipped with a six-position, side mount multiport valve and ABS laterals. Features:

Suggested Installation: Domestic In-ground and above ground pool / hot spa tub Max operating pressure 28 psi / 2.0 bar Max temperature of 40°C (104°F) Universal standard of union connection provided Suggested size of media : 0.5-0.8mm

Features 1.Materials used are dependable and are suitable for all-weater performance 2.Easy-to-use multiport valve let u select any of the valve/filter operation with a simple lever-action 3.UV-resistance surface allows the filter to work under direct sunlight 4.5-10 years life-time.

Functions 1. maximum working pressure: 250kPa/36psi/2.5bar 2. factory testing pressure: 400kPa/58psi/4.0bar 3. size of silica sand: 0.5-1.0mm 4. maximum filtration velocity: 50cbm/h/sq 5. maximum water temperature: 40 degree

Installation Installation had been made simple, the only tools needed is a screwdriver and pipe sealant for plastic. Locate the filter on hard, level surface, preferably in a dry, shaded, and well-ventilated area. 1/ place the empty tank in position. 2/ fill the tank with water to the level that covers the laterals about 1/3 of the tank is recommended.This will avoid damages to the laterals by the force of the sand when pouring into the filter.

P SERIES TOP MOUNT SAND FILTER
